Side by side comparison IPv4 vs IPv6

Before we talk about the two elephants in the room, which are IPv4 and IPv6, you need to know what IP address is in the first place. An IP address is a short form of Internet Protocol, each device that uses the internet service in one form or the other is connected to a network via IP address. Moreover, your IP address is used as an identifier of the device which is requesting access to the webpage on a given network. If you have four devices at home, then you have one IP address assigned to you by the Internet Service Provider (ISP), and your router further makes the subparts of your IP address and shares it with those four devices that you are present in your home network.

General Security Tutorials Jul 13, 21 by Nisal N 16 min Read
Side by side comparison IPv4 vs IPv6

But there are two types of IP addresses, and those are IPv4 and IPv6. Today, we will find out the difference between these two protocols and why IPv6 was created when IPv4 is still present. Moreover, we will also find out which one of these protocols is beneficial for your network usage and why? So let's start.

IPv4

Definition Of IPv4

IPv4 is the fourth generation of the internet protocol and the first of the internet protocols, which makes it possible for the public to access the Internet via an IP address. Before IPv4, the first version of TCP protocol, also known as IPv1, was deployed in 1973. It uses the RFC 675 for the documentation. After that came the second version of TCP 2 in March of 1977.

But soon, it was realized that the network's layering functionality is not being used properly by using the TCP protocols. TCP was used to serve as a host-level end-to-end protocol. While at the same time, it was also used as an internet routing and packing protocol. These two methods need to be separated from each other on the basics of different network layers.

From that point onwards, TCP and IP were split into two different protocols and formed a version number 3 of IP protocols in 1978. After that came the issue of stability, but the usage of IPv4 soon resolved it.

A Bit More Detail On IP Before We Explore IPv4

IP, as we have said earlier, is present on each device that accesses the internet service. IP is also a part of the internet protocol suite, which comes with the transmission control protocol (TCP). Together these two protocols are known as TCP/IP. Most of the networks you use to connect with the Internet handles internet traffic using packet-switching. The packets are the small units of data that are routed through a network from the sender to the receiver.

In general usage, your machine requests to receive the packets from the host, which is the server hosting a website and all of its data. The server gets to know the destination by the IP address, which is present in the header of the request. With the use of packet-switching, many users can share the same data path.

The Relation Of DNS And IP address

Domain Name System is said to be the Internet's phonebook, and it converts the IP addresses into domain names that we can easily remember. For example, Google's IP address is 8.8.8.8. 8.8.4.4, but you don't have to remember the IP address and have to write the domain name, which is "Google.com," on your search bar to visit the web page. On the other hand, with the help of DNS, the computers, servers, and other network devices are able to talk to each other via unique IP addresses.

You can check here for a list of free DNS servers. Read more

How Does IPv4 Work?

IPv4 has a 32-bit number which is annotated in a dotted decimal notation. The 32-bit number has two primary parts: the first one is the network prefix, and the postfix is the host number. If you are a part of a hosted network, all devices will have the same network address, but each has a unique host address, which makes it possible for the server to identify them separately. In the IPv4 network, the devices which are visible to the other network and devices need to have a unique IP address. On the other hand, the devices present within the network require a local individual IP address.

IPv4 is distributed by the Internet Numbers Authority (IANA). The IANA makes sure that each IPv4 address is unique when it is presented on the Internet. At the same time, the IP address needs to have a large space address reserved so multiple devices can use it within its hosted network.

Why Does IPv4 Have A Dotted Decimal Notation?

The IPv4 uses 32-bit addresses, which are denoted by the decimals; in these addresses, each octet or a byte is defined as a separate number. Within the octet, the rightmost part of the octet represents the binary code 20and this number keeps on increasing to the left until the first bit of the octet comes 27or (128). Below are some examples of IPv4 addresses written in both binary and their dotted decimal format.

11010000 01100010 11000000 10101010 = 208.98.192.170

01110110 00001111 11110000 01010101 = 118.15.240.85

00110011 11001100 00111100 00111011 = 51.204.60.59

The IP addresses are written in binary code, which allows computers and the network to read them. The dotted decimal notation is to make the processing of IP addresses in the network more accessible and much faster.

Benefits Of Using IPv4

Below are some of the significant benefits you enjoy when using an IPv4 address for connecting to the Internet.

1.   Encryption

The first thing a user is afraid of is getting their data stolen when surfing the web. Thus it becomes a necessity to encrypt your data and ensure its privacy. IPv4 takes significant security measures and encrypts the data present in the data packets transferred to and fro from different addresses. Hence it keeps the information secure and protected from the latest online threats.

2.   Flexibility

The process of routing different devices to one another is quite efficient and straightforward in IPv4 as it can combine addresses efficiently. Thus, a lot of companies regularly use multicast for their communication to be more specific on the IPv4 network.

3.   Topology Support

IPv4 being a well-used IP protocol is supported by more number of topologies drawings. The main reason for IPv4 for being supportive of topology drawings is because of their simple prefixes, which allows them to fit inside the drawings with ease quickly.

4.   System Support

Again as IPv4 is an older IP addressing protocol, it is supported by almost every network hardware and other device. As a result, if you are running a legacy device or hardware, you can use the IPv4 protocol, and it will indeed work without any issues.

5.   Connectivity

IPv4 was the first IP protocol that the public can use to connect their devices to the network. Moreover, it also allows website owners and servers to verify each device's identity verification even without using NAT.

6.   Data Delivery

The IPv4 uses TCP in order to send the data packets to the correct location; hence if you are working on some important project and want the files to be securely transmitted to the client over the network, you should send them via the network which uses IPv4 addressing protocol.

IPv6

It might surprise you, but IPv6 was first introduced in 1998 as an answer to the shortfall of IP addresses available under the IPv4 protocol, but even now, most of the websites and the network works only on IPv4, and the adoption of IPv6 is relatively slow despite how efficient and secure it is in comparison to IPv4. IPv6 is quite like IPv4, and it is used to identify various devices across the Internet so they can be found and data transfer between the server and the client's machine can take place.

The previous version of the protocol, IPv4, uses a 32-bit addressing scheme and allowed IPv4 to support 4.3 billion unique IP addresses. But with the prices of personal computing going down and the Internet becoming an essential part of our lives, internet devices crossed the 4.3 billion mark.

Fortunately, the Internet Engineering Task Force (IETF) had foreseen this issue and came out with a newer version, IPv6, which uses a 128-bit addressing system that approximately supports 340 trillion trillion addresses. The IPv6 uses eight groups of four hexadecimal digits which are again separated by the colons.

Advantages Of Using IPv6 over IPv4

One of the most obvious benefits that we get from moving to IPv6 from IPv4 is the more number of IP addresses. If we compare the two with each other, we will find that IPv4 has 32-bit addresses and Ipv6 comes with a 128-bit address; without going deep in these two maths, IPv6 has 1,028 times more addresses than IPv4.

As a result, it solves the problem of running out of IP addresses for the foreseeable future. Apart from this, given below are some of the significant advantages which IPv6 has over IPv4.

  • IPv6 comes with built-in support of Quality of Service (QoS).
  • Secondly, both the user and the server are getting a pre-installed network security layer (IPsec).
  • With the use of IPv6, there is no need to use Network Address Translation (NAT), which makes it possible for a network to have end-to-end connectivity at the IP layer.
  • Moreover, multicasting is also one of the added features of IPv6, while you can still get it in IPv4 as it's an optional feature. The use of multicasting will help a user send files to multiple destinations in a single operation in a short time.
  • The IPv6 has bigger packet headers than IPv4, which allows the request from the browser to be more detailed and thorough.

Features Of IPv6

One of the things that might look like an issue for many people is that IPv6 is not made to be backward compatible. The IPv6 was redesigned completely to hold the functionalities of IP addressing. Given below are the features which came with its overhaul.

Bigger Address Space

As we mentioned earlier, IPv6 has four more bits that are used to address the device connected to the Internet. This leads to a massive number of 3.4 x 1038 different IP addresses.

Headers Are Now More Simplified

All the unnecessary information which used to be present in the header of the IPv4 has now moved to the very end of the IPv6 header. Also, the header of IPv6 is twice as big as IPv4's even though the IPv6 address is four times longer than the IPv4 address.

End-to-End Connectivity

Each system connected to the Internet has its own unique IP address. It can receive and send the information to other systems without using the NAT or any other forms of translating components. Now with the use of IPv6, each host can now reach the other host directly on the Internet. But the connection does have some restrictions like Firewall and organization's policies which are put in place to make the connection more secure.

Automatic Configuration

The IPv6 comes with both stateful and stateless auto-configuration modes, which are used by the host devices. As a result, the absence of a DHCP server does not really affect the communication between two hosts or clients and the host.

Better Routing functionality

The websites which are using IPv6 are now much faster than IPv4 because the headers of IPv6 addresses are not filled with unnecessary information. Thus, it makes it easier for the server to easily read the information present in the first part of the header, which is adequate for a router to make the routing decision and send the packet to its destination much quicker.

Addition Of IPSec

The IPsec is a set of commands which are used to make the connection between the two hosts or computing systems encrypted. It allows the data transfer between the two hosts to secure over the public network. IPSec is usually used to set up the VPN connection, and it performs its task by encrypting the data packets and providing authentication proof to the source from where the packets are delivered.

Mobile Friendly

IPv6 was designed to keep the mobility of connected devices in mind. This allows the host of the network, such as a smartphone, to move from one location to the other and will enable it to connect to the same IP address throughout its journey. IPv6 uses the auto IP configuration and Extension headers to make this helpful feature for users.

Extensibility

Last on our list is the IPv6 feature, making it possible to add more information in its header when required. The IPv6 allows the header to be of the size of the data packet if it is needed. While on the other hand, IPv4 only allows the size of 40 bytes as an additional header space.

IPv4 Vs. IPv6 Side By Side Comparison



IPv4

IPv6

IPv4 comes with a 32 bit IP address.

IPv6 has a 128 bit IP address.

IPv4 uses the numeric addressing method, and dots separate the binary bits which are presented in the IP address.

IPv6 is alphanumeric in nature, and a colon separates its binary bits. Furthermore, it contains hexadecimal numbers too.

The header field uses 12 bytes of storage space.

The header field of IPv6 uses 8 bytes of space.

The length of the header is 20 bytes.

Besides this, the length of the header field is 40 bytes.

Header fields used in IPv4 are checksum header fields.

IPv6 does not support checksum fields.

There are three types of addresses: Unicast, broadcast, and multicast.

The three types of IP addresses supported by IPv6 are Unicast, multicast, and anycast.

Moreover, there are five different classes of IP addresses, and they are presented in the form of alphabets that start from A and end at E.

IPv6 has an unlimited number of IP addresses, and it does not have any naming scheme like IPv4.

In order to use the Internet using IPv4 in the new system, you first need to configure it so it can communicate with other machines on the network. IPv4 comes with a support of Variable Length Subnet Mask.

IPv6 does not require the user to configure it, but if there are some unique features that a user wants to take the benefit of, they might need to configure the IP to use it optimally.

The fragmentation in IPv4 is done by sending the forwarding the routes

In addition to this, the fragmentation is done by the sender of the request.

IPv4 comes with the support of Routing Information Protocol (RIP) in order to support routed daemon technology.

The RIP support is not present in IPv6.



There are no security layers present in IPv4; it was not designed by keeping security in mind.



IPv6 comes with a security layer called Internet Protocol Security (IPsec), and it can be used with proper key infrastructure.

The packet size of IPv4 is 576 bytes, and the fragmentation of the packets is an optional feature that a user can deploy according to their need.

Likewise, the packet size of IPv6 is 1208 bytes which don't require fragmentation.

Lastly, IPv4 uses the dot-decimal address notation. As a result, it is not suitable for mobile networks.

The IPv6 protocol is presented in hexadecimal, colon-separated notation. This makes it suitable for mobile networks.

Wrapping Up

The IP addresses are used all over the world to make the network send and receive data packets from one host to the other. The IPv4 was the original version which was launched in 1983 for the public to access the internet connectivity. But IPv4 only had 4.3 billion unique addresses, which are exhausted now.

Thus, IPv6 was introduced, and in the coming years, most websites and e-commerce businesses will move from IPv4 to IPv6 as it is better in almost every way possible. A number of hosting sites are still dependent on IPv4, but we are likely going to see a change in the near future.
